Headlight ECU Tester

When LED headlights are used in modern vehicles, each headlight is operated by its own ECU, which individually controls and monitors the numerous LEDs.

We have developed several testers for various LED headlight control units. These systems are capable of capturing, analyzing, and transmitting data streams between the control units and headlights directly to HIL systems.

In addition to numerous manipulation, emulation, and trigger functions, the systems provides further measurement and generation functions.

For control and data visualization, we developed a Qt-based application and also implemented an integration into CANoe using CAPL scripts and C#-based user interfaces.

Our Services

  • Concept and development of the entire tester
  • Development of the Qt software
  • Implementation of the CANoe integration

Technologies

Hardware

  • Xilinx Zynq-SoC – FPGA SoC with integrated ARM processor
  • Multilayer PCB

Software

  • Embedded Linux
  • Qt4/5 – framework for developing graphical user interfaces
  • CANoe – development and test environment for automotive networks
  • CANoe Customized Panel Controls

Programming Languages

  • C/C++
  • VHDL
  • CAPL – programming language for simulation and testing of automotive communication in CANoe
  • C#

Interfaces

  • LVDS
  • Ethernet
  • TCP/UDP/IP
  • CAN
  • RS232

Tools

FPGA Development

  • Xilinx Vivado – FPGA synthesis and implementation
  • Xilinx SDK (Eclipse) – C/C++ development environment for embedded software on Xilinx systems
  • GHDL – simulation and verification of FPGA logic

Embedded Software

  • Yocto – creation of embedded Linux images
  • Embedded Linux – operating system for embedded systems
  • KDevelop – C/C++ development environment

Hardware Development

  • Eagle – schematic design and PCB layout
  • LTspice – simulation of analog circuits

Test & Analysis

  • CANoe – development and test environment for automotive networks

Documentation

  • Doxygen – source code documentation
